DESCRIPTION

A standard size LED in an extremely compact size of 10.2mm x 4mm, with two standard TinyLily sewtabs and a current limiting resistor, so you don’t have to worry about blowing it up or adding an external resistor. Available with Red, Green and Amber LED color options.

TECH SPECS

• Washable
• Two Sewtabs – 1.2mm in diameter, easy to use with standard conductive thread and needles
• Robust Gold Finish – makes soldering easy and is non-corrosive

Power Requirements

• Voltage: 3.0V - 5.5V
• Current:
• 1.5mA per LED (3.0V)
• 5.0mA per LED (5.0V)

Dimensions

• Dimensions: 10.2mm x 4mm (0.40 inches x 0.18 inches)
• Max Height: 1.44mm (0.057 inches)
• Ultra-thin 0.61mm (0.024 inches) PCB
• Weight: .06 grams (0.002 ounces)

DOWNLOADS

• Schematic
• Eagle Files
• Example Arduino Sketch
• CAD 3D and 2D Files
