DESCRIPTION

This Wireling lets you measure ambient light and color temperature via the TCS3472 Color Sensor and onboard emitting LEDs. This I²C sensor measures red, green, blue and clear light with 16-bit resolution. The interrupt registers may be used to set threshold values independently for each color register (RGBC) to improve system efficiency and avoid continuous polling of the sensor.

New to Wirelings? Check out the Wireling Overview!

Note* 5-Pin Wireling cables not included and sold separately.

TECH SPECS

AMS TCS3472 Color Sensor Specs

• 16-bit color resolution
• I²C Communication Protocol
• Ambient Light Detection
• Color Temperature Detection
• 2.5µA typ. during Sleep Mode
• 65µA typ. during Wait State

QBLP674-IWM LEDs

• Diffused lens for aid in color sensing
• Can be toggled on/off in Arduino Sketch

TinyDuino Power Requirements

• Voltage: 3.0V - 5.5V
• Current:
• Color Sensor: 2.5uA (Low Power Sleep Mode)
• LED: 30mA

Pins Used

• A5/SCL - I²C Serial Clock line
• A4/SDA - I²C Serial Data line

Dimensions

• 10mm x 10mm (.394 inches x .394 inches)
• Max Height (from the lower bottom of Wireling to upper top Wireling Connector): 4.30mm (0.17 inches)
• Weight: 1 gram (.04 ounces)
